| Feature |
Value |
| Max. Workpiece Diameter (mm) |
220 |
| Max. Workpiece Weight (kg) |
25 |
| Max. Module |
M6 |
| Table Diameter (mm) |
240 |
| X-Axis travel (mm) |
220 |
| Y-Axis travel (mm) |
170 |
| Z Axis travel (mm) |
350 |
| Hob Rotation Angle (degrees) |
-90 |
| Hob Arbor Taper |
NT No. 40 |
| Max. Pocket Knife Diameter / Length |
180/190 |
| Max. pocket knife speed (rpm) |
1500 |
| C Axis max. Speed (rpm) |
250 |
| X Axis No-load Speed (m/min) |
1200 |
| Y Axis No-load Speed (m/min) |
250 |
| Z Axis No-load Speed (m/min) |
1200 |
| Distance from Table Top to Center (mm) |
200-550 |
| Distance from Table Center to Hob Center (mm) |
15-235 |
| X Axis Motor (Nm) |
4.3/20.5 |
| Y Axis Motor (Nm) |
1.5/4.7 |
| Z Axis Motor (Nm) |
4.3/20.5 |
| C Axis Motor (Nm) |
30.6/450 |
| Power Requirements (kaw) |
35 |
| Control unit |
SIEMENS 840D SL |
| Machine Size (LxWxH) |
3.4x2.3x2.5 |
| Machine Weight (tonnes) |
10500 |
